המכשיר מגיע ללא לחץ אוויר
|
nput Voltage
|
220V/50Hz(60Hz)
|
|
Input Current
|
30A
|
|
Input air source
|
Compressed air pressure is not bigger than
10Bar
|
|
Output Voltage
|
5.5V
|
|
Putput Power
|
12KVA
|
|
Pulse Current
|
2100A
|
|
Discharge Time
|
Longest 20ms
|
JG-19 Related Dimension
-
Dimension(L*W*H): 550*205*355mm
-
The distance between Electrode and welding machine: 85mm
-
Electrode diemnsion: 3D*70mm
-
Workbench Dimension and its adjustment range: 150mm*105mm
-
Max workpiece height 100mm
-
Minmum electrode distance:: 0.1m
Features:
Double-pulse welding, It is more reliable;
CPU control, LED large digital display;
Ten user-defined welding procedures;
Locked state technology, to ensure that the correct trigger;
Can be flexibly used in automatic production line;
Locked energy technology, to ensure welding output energy does not exceed 1% default value, quality uniform;
Digital power regulation, pre-press time programmable;
Radio (RFI) and eletromagnetic valve interference(EMI) protection;
Long, short pulses can be chose, more suitable for fine welding, a wide rang of applications;
Compatiable with pneumatic and feet welding head, match flexible.
תחנת ריתוך לסוללות,POWER 787A+ Microcomputer pulse Spot Welders,תחנת הלחמה,מתקן להלחמת סוללות ליתיום
