Please Notice
1：Bisida's BMS is an integrated scheme, and SOC's accuracy is very high. The battery voltage, capacity, and internal resistance are consistent, and BMS can work better.
Only people with professional electrical knowledge are recommended to buy assembly. Thank you for understanding
2:Free send 2.0mm standard, 400mm long cable, black negative on the right.10strings of cables are 11pins (the number of each string is different, the number of cables is the number of strings + 1)
(7S-8P,13S-14P）Please contact the seller if additional cables are required
Common port: B- is the total negative electrode of the battery, C- is the negative electrode for charging
Size table：
15A~20A:34MM*60MM*8MM
25A~30A:48MM*75MM*8MM
35A:55MM*98MM*10MM
40A~50A:64MM*125MM*10MM
60A:64MM*145MM*12MM
80A~120A:80MM*160MM*17MM
Features:
• The main functions are: over charge protection, over discharge protection, over current protection, short-circuit protection, temperature protection, Voltage balance(passive balance), etc.
• Can provide 3S to 24S series solutions, provide 5A to 200A working current customization. Different voltages, currents. There are different parameter details. If you need to confirm. Please communicate with the seller to confirm accurate data.
• Use top quality (A-level) protective integrated circuit IC, from the solution of Industry car level.BMS manufactured by high quality Mos and IC imported.
• Double-sided PCB circuit board ,high anti-corrosion, high water resistance, high impedance ESD conformal Coating.Silicone sheet + aluminum sheet double-layer heat dissipation. Three anti-glue + insulation sheet, double-layer electrostatic insulation
• Support customer samples, oem/odm, customization, if you have special needs, you can contact customer service. We will provide you with a complete solution.
Applicable battery:
Nominal voltage (single cell): 3.6V/3.7V lithium ionbattery
Charging voltage:4.25V*string number
Instantaneous current: 3 to 5 times the working current.
Charging current: recommended to be less than 10A.
Temperature protection: -20 ℃ ~ 70 ℃
Package Contents:
Battery protection board*1
Cable*1
The size and model of this product will change with changes in voltage and current.
If you have exact requirements, please communicate with the seller to confirm the model
